| Business Type | Manufacturer, Exporter, Supplier |
| Application | Drone Obstacle Detection And Terrain Mapping |
| Number Of Flower | Radar System |
| Brand Name | Bharath |
| Click to view more | |
Product Details
Country of Origin
India
Technology
Millimeter-wave Radar
Purpose
Detect And Avoid Obstacles In Drone Flight Path
Range
30m
Frequency Band
77-81 GHz
Field Of View
60 Degrees
Temperature Range
-40°C To +65°C
Integration
Seamless Integration With Drone Flight Controllers
Environmental Resilience
Operates In Various Weather Conditions
Feature
Terrain Following,Collision Avoidance,Object Detection,Terrain Mapping,Enhanced Safety,Efficient Flight,Precise Agriculture,Situational Awareness,Autonomous Operation,Increased Reliability
Operating Temperature
-40°C To +65°C
IoTechWorld Avigation designs “Radar” (Bharath Radar) systems, “Terrain following” & “Collision Avoidance” which provides unmatched accuracy, reliability, and performance.
Navigate complex environments with confidence using our radar, which provides accurate terrain mapping and obstacle detection.
- Advanced sensing technology, Empowering your Drone.
- Provides object detection & terrain mapping.
- 77-81 GHz frequency band, 30m range, & 60° field of view.
- Reliability & Performance, even in challenging environments (-40°C to +65°C).
Additional Information
Enhanced Safety
Collision prevention through real-time terrain mapping and obstacle detection.
Efficient Flight
Optimized flight paths for reduced energy consumption and increased range.
Precise Agriculture
Accurate data collection for optimized farming practices and yield improvement.
Situational Awareness
Real-time information about the surrounding environment.
Autonomous Operation
Real-time information about the surrounding environment.
Increased Reliability
Reduces reliance on manual piloting for safer and more consistent operations.
Component Specifications
| Parameter | Specification (Terrain) | Specification (Collision) |
| Azimuth Angle | ±15° | ±50° |
| Elevation Angle | ±5° | -4˜+8° |
| Max EIRP (dBm) | 16 | 16 |
| Ranging Accuracy (m) | ±0.1 | ±0.1 |
| Detect Range (m) | 0.10-20 | 02-30 |
| Range Resolution (m) | 0.12 | 0.12 |
| Transmitting Frequency (GHz) | 77-81 | 77-81 |
| Refresh Rate (Hz) | 30 | 30 |
| Bandwidth (GHz) | 4 | 4 |
| Operating Voltage (VDC) | 4.5~5.5VDC | 4.5~5.5VDC |
| Operating Temperature | -40°~+65° | -40°~+65° |
| Data Interface | CAN | CAN |
| Power Consumption | 2.08 | 2.08 |
| Size (mm) | 88.7*66.4*15.2 | 88.7*66.4*15.2 |
| Weight (g) | 90 | 90 |
