Product Details
Efficiency
Designed For Efficient Operation
Torque
Provides Sufficient Torque For Flight Maneuvers
Availability
Lightweight Construction
Voltage (VDC)
21.6V – 60V
Thrust (gf)
8750 (gf)
Torque (Nm)
3.00 Nm
Speed (RPM)
5600
Input Power (W)
2073.6 W
Output Power (W)
1755.8 W
Temperature (C)
120 °C
Communication interface
CAN, PPM, USB
Smart UAV status lights
Mode specific notification LED
Over Temperature Protection
Motor Limits On Temperature Above 110 Degree
Over Current Protection
Notification Led Blinks if Current Reaches Above 40 Amps
Control Method
FOC
KV Rating
180KV
Power Output
Suitable For Mid-to-large Sized Drones
Cooling
May Incorporate Cooling Features
Compatibility
Compatible With Various ESCs And Propellers
Rotor Load
3-5kg
Thrust
Up To 9Kgf
Waterproof Rating
IPX7
Control
Advanced FOC Vector Control
- Powerful & Reliable propulsion system for industrial grade drones.
- Generates 3-5kg rotor load with up to 9Kgf thrust.
- IPX7 waterproof rating for durability in harsh conditions.
- Advanced FOC vector control for optimal & efficient power delivery.
Additional Information
Enhanced Efficiency
Efficient control algorithms help optimize motor performance and reduce wasted energy.
Powerful Performance
The motor’s design may allow for high torque density, enabling it to handle demanding loads.
Reliable Operation
Effective thermal management helps prevent overheating and ensures reliable operation.
Lightweight Design
The motor’s design may be optimized to reduce weight without compromising performance.
Precise Control
The motor likely uses sophisticated control algorithms to ensure precise control over speed, torque, and position.
Versatile Compatibility
Operates within a wide voltage range, making it compatible with various battery configurations.
