Product Details
Speed
High RPM
Torque
Provides sufficient torque for various flight maneuvers and payload carrying
Efficiency
Designed For Efficient Operation, Minimizing Power Consumption
KV Rating
150KV
Power Output
Likely Suitable for Mid-to-large Sized Drones or other Applications Requiring Moderate to High Power
Compatibility
Compatible with Drone Escs
Voltage (VDC)
21.6V – 60V
Thrust (gf)
8973 (gf)
Torque (Nm)
3.04 Nm
Speed (RPM)
4850 (at 100% throttle)
Input Power (W)
1897.7 W
Output Power (W)
1527.7 W
Temperature (C)
70 °C
Communication interface
CAN, PPM, USB
Smart UAV status lights
Mode specific notification LED
Over temperature protection
Motor Limits On Temperature Above 110 Degree
Over Current Protection
Notification Led Blinks if Current Reaches Above 40 Amps
Control Method
FOC
- Powerful & Reliable propulsion system for industrial grade drones.
- Generates 3-5kg rotor load with up to 9Kgf thrust.
- IPX7 waterproof rating for durability in harsh conditions.
- Advanced FOC vector control for optimal & efficient power delivery.
Additional Information
Enhanced Efficiency
Efficient control algorithms help optimize motor performance and reduce wasted energy.
Lightweight Design
The motor’s design may be optimized to reduce weight without compromising performance.
Powerful Performance
The motor’s design may allow for high torque density, enabling it to handle demanding loads.
Reliable Operation
Effective thermal management helps prevent overheating and ensures reliable operation.
Precise Control
The motor likely uses sophisticated control algorithms to ensure precise control over speed, torque, and position.
Versatile Compatibility
Operates within a wide voltage range, making it compatible with various battery configurations.
